Radiation Oncology Equipment

Charge Ranges : Three ranges, pC, nC & mC Selectable from the front panel

Display : 4½ digit LCD

(i)pC range
Resolution : 0-19999pC
1pC

(ii) nC range
Resolution : 0-199.99nC
0.01nC

(iii) mC range
Resolution : 0-19.999 mC
0.001mC

Detector : Hermetically sealed A ir Equivalent Ionisation chamber

Range : 0-200mR/h

Display : 3½ digit LED

Time constant : 5 seconds

Resolution : 0.1mR/h

Brand Name : Radimage

Alarm Timeing : 30 seconds

Operation : Auto Reset

Technique : Micro Controller Based Technology

Features : Simple to install and easy to use

Brand Name : Ludlum

Model : 9DP

Radiation Detected : gamma & X‐rays above 25 keV; beta above 1 MeV

Operating Ranges : With R/hr units : 0–500 μR/hr, 0–5 mR/hr, 0 –50 mR/hr, 0–500 mR /hr, 0–5 R/hr

Operating Ranges : With Sv/h units : 0–5 μSv/h, 0–50 μSv/h, 0–500 μSv/h, 0–5 mSv/h, 0–50 mSv/h

Model : 375

Brand Name : Ludlum

Indicated Use : Area monitoring

Linearity : Reading within 10% of true value

Display : Four-digit LED display with 2 cm (0.8 in.) digits

Brand Name : CIRS

Material : Plastic Water® DT

Density, g/cc : 1.04

Electron Density x 10^23, per cc : 3.35

Ratio to H₂O : 1.003

Brand Name : RIT

Dimensions : 24 cm x 24 cm x 4 cm

Weight : <1.95 kg

Composition : Solid Water

Features : Alignment marks for room lasers, Can be placed directly on the EPID surface

Dimensions : 16.5 cm X 30 cm X 20 cm (6.5" x 11.8" x 7.9")

Weight : ~7 kg (15 lb)

Materials : Proprietary Epoxy Resins

Includes : E2E® SBRT Phantom
Carrying and Storage Case

Optional Accessories : Abdomen with Data Pack & 3D Spine, CBCT Image Quality Phantom

Response Time. : 9ms

Bar Coded Planchet : 600°C

Powder Vibrator : 0 to 25 sec.

Temperature Profiles : 10 nodes

Internal Micro Processor : (C/C++) RS 232

Brand Name : Medironix

Maximum cutting area with one block : 380x380mm

Maximum distance of source‐to‐film : 1400mm

Maximum distance of source‐to‐tray : 560mm

Maximum cutting thickness : 140mm

Brand Name : A2J HORUS

HORUS Laser color (wavelength) : red (638 nm), green (520 nm)

Line width (up to 4 m distance) : < 1 mm

Line length ( at 3 m distance) : > 3 m

Laser class : 2

Brand Name : CIRS ATOM®

Model Available : Six

Range Available : 1‐ year, 5‐year and 10‐year phantoms

Thickness : 25 mm

Material : Epoxy Resins
